EZI-Action
Adaptor Fittings

There is an Ezi-action® Adaptor Fitting to secure and lock the drum pump into every common thread configuration for bulk containers with at least a 42mm wide opening.

Get a quote
Fittings adapter connected to a black motorcycle.
EZI - action M adapter fittings.

For internal threaded openings we provide Ezi-action® M Adaptor Fittings. For external threaded openings we provide Ezi-action® C Adaptor Fittings.

EZI-ACTION MBSP55

Combines the Ezi-action® MBSP and M55 Adaptor Fittings

  • The Ezi-action® MBSP55 secures the Ezi-action® Drumpump into either a metal drum with British Standard fine thread (58mm outside diameter of bung)  opening or into a plastic drum with 56 x 4 buttress opening.
  • Effective securing of Ezi-action® Drumpump into two styles of drum with one fitting.
  • Simplifies the number of fittings required.
  • Less plastic so better for the environment.

Do you need a different Ezi-action® Adaptor Fitting to that supplied with your Ezi-action® Drumpump?

The Ezi-action® M fittings required in NZ and Australia are MBSP55, M63 and M69.

The thread requirement can change depending on the origin of the drum.

Do you have an unusual drum or container opening?

We have a solution from varying the size of an O ring to customising a specific fitting.

We are pleased to work with you to ensure you get the best fitting to secure your Ezi-action® Drumpump into your drum, barrel, jerry can, container or IBC.

If you’d like to work with our sales team in your area then please Contact Us and click on your location on the world map.

Features & Benefits
Resources

Features & Benefits

  • Durable and chemical resistant.
  • No tools required.
  • Hand tightening secures the Ezi-action® Drum Pump into the drum or container.
  • Chemical resistant locking ring
  • grips the drum pump shaft when the Ezi-action® Adaptor Fitting is tightened.
  • Will slide when loosened and can be positioned anywhere on the shaft.
  • Allows transfer of Ezi-action® Drum Pump between different drums and containers.

Adaptor Fitting Guide

1. How to Determine the Ezi-action® Adaptor Fitting for a Drum with internal threaded opening.

a. Measure across the opening internal thread width.

b. Measure the width of the bung.

Measuring drum opening
This opening measures close to 55mm.
Measuring width of bung
This bung measures close to 55mm.

Both these drums require an Ezi-action® M55 fitting.

2. How to Determine the Ezi-action® Adaptor Fitting for a Container with external threaded opening.

a. Measure across the opening outside thread width.

b. Examine the thread pitch.

The width is 55mm.
This container requires an
Ezi-action® C55 Fitting
This container requires an Ezi-action® C63Int Fitting.

‍

3. How to Determine the Ezi-action® Adaptor Fitting for an IBC

Note: The IBC needs a small inner cap within a large cap. ( see photo)

a. Remove the small inner cap.

b. Measure the internal opening and examine the thread.

If the opening has width of 58mm with a fine thread the IBC requires an Ezi-action® MBSP Adaptor Fitting.

If the opening has width of 55mm with a medium thread the IBC requires an Ezi-action® M55 Adaptor Fitting.

The most commonly required fittings for IBC's are the Ezi-action® MBSP and M55 adaptor fitting.

‍
